“EKL” series is one of the most powerful lighting towers, entire hydraulic system with electrical controlling make every operation to be fast and flexible, more safe and reliable. The six most shining floodlights can illuminate an area of 500 meters radius.
The galvanized mast and the powder coated canopy suit the outdoor environment for a long time. The heavy-duty muffler and the soundproof canopy make the noise level under 70 dB(A) at 7 meters away.
The electrical controlling hydraulic system with the over center valves and hydraulic locks make every operation smooth and safe, and can keep the hydraulic ram in any position for a long time even when the oil leaks out from the pipes or connecters.
The light bar can be adjusted from horizontal to vertical, and the mast can rotate within 340°by the control panel operation.
The simple and clear graphic indication and operating mark on the control panel. Automatic light control system, all of the lights turn on or turn off in order.
All the outdoor electrical plugs and sockets are at least IP44 protective class. The lights are IP65 or IP66 protective class.
The external IP44 output sockets will power other equipments or electric tools whenever.
The excellent-quality and multi-fault protection generator with the low-emission diesel engine and brushless alternator can power all of the lights stably and continuously. The fully bunded tank avoid the fuel spilling out.
The hydraulic legs of individual operation are able to support stably and reliably even on rough ground, so the lighting tower can also work in the 10 grade windy weather.
Option equipment:
1. Radio remote control system: It can remotely adjust light bar tilt and mast rotation within diameter 100 meters. Another option is SMS remote control function, the lighting tower will be started or stopped remotely by the relative mobile phone, and it can receive the fault alarm message from the lighting tower’s controller.
2. The searching lighting mode (it need to fit particular parts): Then the lighting tower can light circularly in order within 180° at several different titlt angles, especially suit the warehouses, camps, border checkpoints or special monitoring area.
Please call us on +86-13922523585 or email Sam@etonepower.com and our specialist team would be delighted to advise you on the best lighting for your site.
Standard Equipment
6HKP6000
Length (mm)
4950 (3820, Detached the tow bar )
Width (mm)
1880
Height (mm)
2150
Mast Height(m,Fully Extended)
10
Weight (gross)
2530kg
Engine model
V1505-BG(Kubota)
3TNV88(Yanmar)
403D-15G(Perkins)
Frequency(Hz)
50
60
50
60
50
60
Speed(rpm)
1500
1800
1500
1800
1500
1800
Continued Power(kVA)
12.5
15
12.5
15
12.5
14.5
Number of Cylinders
3
Diesel Engine Characters
4-cycle, In line, Watercooled Diesel
Combustion Type
Precombustion
Direct Injection
Indirect Injection
Engine Aspiration
Natural
Emission Level
Stage3
Tier4
Stage3
Tier4
Stage2
Tier4
Alternator
Brushless & Single phase
Rating Voltage (V)
230
Alternator Insulation
class H
Fuel Tank Capacity
228 liters (60 US Gallons)
Fuel Tank Operating Hours
60 hours
Type of Lights
Metal Halide Floodlight
Number & Power of Lights
6×1000W
Mast Lifting & Extension
Hydraulic operation
Mast Rotation
340° Manual operation
Light Bar Tilt
90° Electric operation
Automatic Light Controller
ETONE(Including generator control function)
Stabilizing Legs
Hydraulic operation
Trailer Suspension System
Leaf spring axle & stable hitch in height
Braking System
Drum brake
Hitch
Ball or O ring
Tire Rim Size
16”
Output Sockets
1 PCS (230V,10A)
Acoustic Pressure
70dB(A) at 7 meters away
Max. load quantity in
a 20' container (sets)
3
