The winch with self-locking;
The mast can be extended to 9 meters fully;
Locating pin, locking pins, position limiting block ensure all operations to be safe and reliable;
Tilt the lightbar and rotate the mast 359°manually to adjust the illuminated area;
Assemblied with 4 high brightness and good shooting spotlights and floodlights are also optional;
Using key switch or controller to manually start or stop the genset, control each light independently
just by its own independent switch;
The excellent-quality and multi-fault protection generator with the low-emission diesel engine and brushless alternator can power all of the lights stably and continuously;
IP44 light plug and sockets;
The AL-KO Hexagon rubber suspension system is suitable for variously rough road, and its maintenance-free axis’s service life will be at least 20 years;
Please call us on +86-13922523585 or email Sam@etonepower.com and our specialist team would be delighted to advise you on the best lighting for your site.
Standard Equipment
4TL4000
Length (mm)
4600
Width (mm)
1500
Height (mm)
1850
Mast Height(m,Fully Extended)
9
Weight (gross)
890kg
Engine model
D1105-BG
(Kubota)
3TNV76
(Yanmar)
403D-11G
(Perkins)
380
（Lester）
Frequency(Hz)
50
60
50
60
50
60
50
60
Speed(rpm)
1500
1800
1500
1800
1500
1800
1500
1800
Continued Power(kVA)
7
9
7
9
7
9
7
9
Number of Cylinders
3
Diesel Engine Characters
4-cycle, In line, Watercooled Diesel
Combustion Type
Precombustion
Direct Injection
Indirect Injection
Direct Injection
Engine Aspiration
Natural
Emission Level
Stage3
Tier4
Stage3
Tier4
Stage2
Tier4
N.A.
Tier4
Alternator
Brushless & Single phase
Rating Voltage (V)
230
Alternator Insulation
class H
Fuel Tank Capacity
95 liters (25 US Gallons)
Fuel Tank Operating Hours
60 hours
Type of Lights
Metal Halide Spotlight (Local Brand)
Number & Power of Lights
4×1000W
Mast Lifting & Extension
Manual operation
Mast Rotation
330° Manual operation
Light Bar Tilt
Manual operation
Stabilizing Legs
Manual operation
Trailer Suspension System
Hexagon rubber axis
Hitch
Ball or O ring
Tire Rim Size
14”
Acoustic Pressure
75dB(A) at 7 meters away
Max. load quantity in
a 20' container (sets)
6
