Light Tower - 4HVL6000

  • Product Brand:
  • Product Model:
  • Product Description:

 The safe and reliable 8-section telescopic mast powered by hydraulic ram can be extended to 9 meters altitude fully;
 The light bar can be adjusted from horizontal to vertical by the control panel operation;
 The hydraulic one-way valve with electric controlling can make the hydraulic ram keep the any position for long time;
 The mast can rotate within 330° manually;  The inertia braking system can mostly reduce the collision when the vehicle is braking;
 The heavy-duty muffler makes the noise under 75 dB(A) at 7 meters away;
 The galvanized mast and the powder coated canopy suit the outdoor environment for a long time
 The electrical devices of the lights are fitted in the weatherproof canopy, and it’s easy to fix;
 The most cable can be retracted in the protective stainless steel tube;
 The excellent-quality and multi-fault protection generator with the low-emission diesel engine and brushless alternator can power all of the lights stably and continuously;
 The smaller size is easy to be loaded. The maximum would be 9 sets in a 40 feet container;
 The AL-KO Hexagon rubber suspension system is suitable for variously rough road, and its maintenance-free axis’s service life will be at least 20 years;
 Four manual legs of individual operation are able to support stably and reliably even on rough ground, so the lighting tower can also work in the 9 grade windy weather;
 The base frame with fully bunded tank avoid the fuel spill out.

Please call us on +86-13922523585 or email Sam@etonepower.com and our specialist team would be delighted to advise you on the best lighting for your site.

Standard Equipment
4HVL6000
Length (mm)
3420(2880,Detached the tow bar)
Width (mm)
1760
Height (mm)
2280
Mast Height(m,Fully Extended)
9
Weight (gross)
1660kg
Engine model
D1105-BG
(Kubota)
3TNV82A
(Yanmar)
403D-11G
(Perkins)
385
(Lester)
Frequency(Hz)
50
60
50
60
50
60
50
60
Speed(rpm)
1500
1800
1500
1800
1500
1800
1500
1800
Continued Power(kVA)
9.5
10.5
9.5
11.5
9
10
9
11
Number of Cylinders
3
Diesel Engine Characters
4-cycle, In line, Watercooled Diesel
Combustion Type
Precombustion
Direct Injection
Indirect Injection
Direct Injection
Engine Aspiration
Natural
Emission Level
Stage3 Tier4 Stage3 Tier4 Stage2 Tier4 N.A. Tier4
Alternator
Brushless & Single phase
Rating Voltage (V)
230
Alternator Insulation
class H
Fuel Tank Capacity
120liters (31 US Gallons)
Fuel Tank Operating Hours
50 hours
Type of Lights
Metal Halide floodlight
Number & Power of Lights
4×1000W
Mast Extension
Hydraulic operation
Number of Mast Section
8
Mast Erection Time
<30 Seconds
Mast Rotation
330° Manual Operation
Light Bar Tilt
90° DC Electric operation
Stabilizing Legs
Manual operation
Trailer Suspension System
Leaf spring axle & stable hitch in height
Braking System
Drum brake
Hitch
Ball or O ring
Input terminals & MTS
1 PCS (230V,10A)
Acoustic Pressure
70dB(A) at 7 meters away
Max. load quantity in
a 20' container (sets)
5
