Light Tower - 4HVP4000

  • Product Brand:
  • Product Model:
  • Product Description:



The safe and reliable 8-section telescopic mast powered by hydraulic ram can be extended to 9 meters altitude fully;
 The light bar can be adjusted from horizontal to vertical by the control panel operation;
 The hydraulic one-way valve with electric controlling can make the hydraulic ram keep the any position for long time;
 The mast can rotate within 330° manually;  The inertia braking system can mostly reduce the collision when the vehicle is braking;
 The heavy-duty muffler makes the noise under 75 dB(A) at 7 meters away;
 The galvanized mast and the powder coated canopy suit the outdoor environment for a long time
 The electrical devices of the lights are fitted in the weatherproof canopy, and it’s easy to fix;
 The most cable can be retracted in the protective stainless steel tube;
 The excellent-quality and multi-fault protection generator with the low-emission diesel engine and brushless alternator can power all of the lights stably and continuously;
 The smaller size is easy to be loaded. The maximum would be 9 sets in a 40 feet container;
 The AL-KO Hexagon rubber suspension system is suitable for variously rough road, and its maintenance-free axis’s service life will be at least 20 years;
 Four manual legs of individual operation are able to support stably and reliably even on rough ground, so the lighting tower can also work in the 9 grade windy weather;
 The base frame with fully bunded tank avoid the fuel spill out.

Please call us on +86-13922523585 or email Sam@etonepower.com and our specialist team would be delighted to advise you on the best lighting for your site.

Standard Equipment
4HVP4000
Length (mm)
3100 (2100,Detached the tow bar )
Width (mm)
1450
Height (mm)
2250
Mast Height(m,Fully Extended)
9
Weight (gross)
1355kg
Engine model
D1105-BG
(Kubota)
3TNV76
(Yanmar)
403D-11G
(Perkins)
385
(Lester)
Frequency(Hz)
50
60
50
60
50
60
50
60
Speed(rpm)
1500
1800
1500
1800
1500
1800
1500
1800
Continued Power(kVA)
7
9
7
9
7
9
7
9
Number of Cylinders
3
Diesel Engine Characters
4-cycle, In line, Watercooled Diesel
Combustion Type
Precombustion
Direct Injection
Indirect Injection
Direct Injection
Engine Aspiration
Natural
Emission Level
Stage3 Tier4 Stage3 Tier4 Stage2 Tier4 N.A. Tier4
Alternator
Brushless & Single phase
Rating Voltage (V)
230
Alternator Insulation
class H
Fuel Tank Type Bunded Tank
Fuel Tank Capacity
120liters (31 US Gallons)
Fuel Tank Operating Hours
72 hours
Type of Lights
Metal Halide Floodlight (Original GEWISS)
Number & Power of Lights
4×1000W
Mast Extension
Hydraulic operation
Number of Mast Section
8
Mast Erection Time
<30 Seconds
Mast Rotation
330° Manual Operation
Light Bar Tilt
90° DC Electric operation
Stabilizing Legs
Manual operation
Trailer Suspension System
Hexagonal rubber suspension
Braking System
Inertia drum braking with stable hitch in height
Hitch
Ball or O ring
Output Sockets
1 PCS (230V,10A)
Input terminals & MTS
1 PCS (230V,10A)
Acoustic Pressure
70dB(A) at 7 meters away
Max. load quantity in
a 20' container (sets)
8
