Light Tower - 3VB3000

  • Product Brand:
  • Product Model:
  • Product Description:

1. Glare-free lighting
Balloon light gives enough light to a work area but eyes are never blinded by glare even if seeing the light directly. It is gentle to surrounding traffic.
2. Wide area & 360°illumination
Balloon Light can radiate the homogeneous light far and wide from the balloon to all directions. Balloon Light that forms less darker shadow is also make the work more Efficient and comfortable.
3. Safety and reliability
The texture of the envelope is non flammable. Integrated thermo-switch protects light from power variations and helps control internal temperatures.
4. Easy installation
Since Balloon Light has integral Velcro fastener, message strip can be quickly installed with no tools.
5. Five-section of the lighting tower can be extend 7meters fully and internal reflective dome combine to light up a larger area。

Please call us on +86-13922523585 or email Sam@etonepower.com and our specialist team would be delighted to advise you on the best lighting for your site.

Standard Equipment
3VB3000
Length (mm)
2180(1160,Detached the tow bar)
Width (mm)
1050
Height (mm)
2240(2070,Detached the lights)
Mast Height(m,Fully Extended)
7
Weight (gross)
420kg
Engine model
186F (CHANGCHAI)
Frequency(Hz)
50
60
Speed(rpm)
3000
3600
Continued Power(kVA)
4.2
5.0
Number of Cylinders
1
Diesel Engine Characters
4-Cycle, In line, Aircooled diesel
Combustion Type
Direct injection
Engine Aspiration
Natural
Emission Level
N.A.
Tier4
Rating Voltage (V)
230
Alternator Insulation
class H
Fuel Tank Capacity
38 liters (10 US Gallons)
Fuel Tank Operating Hours
32hours
Type of Lights
balloon light
Number & Power of Lights
3×1000W
Mast Extension
Manual operation
Number of Mast Sections
5
Light Tilt
Manual operation
Stabilizing Legs
Manual operation
Trailer Suspension System
Hexagonal rubber suspension
Hitch
Ball or O ring
Tire Rim Size
13”
Output Sockets
1 PCS (230V,10A)
Input Sockets & MTS
1 set (230V,16A)
Acoustic Pressure
78dB(A) at 7 meters away
Max. load quantity in
a 20' container (sets)
10
